2Pack-18-Inch Plastic Floor Fan, 3-Speed Settings, 5-Blade Airflow

18-Inch Plastic Pedestal Fan | Comprehensive Product Description

---

Product Overview

The 18-inch pedestal fan is a high-airflow cooling solution suitable for homes, retail shops, and offices. It features a low-noise motor, a five-blade design, three adjustable speed settings, wide-angle oscillation, and an adjustable-height stand. Easy to assemble and built with a stable base, this fan offers excellent value and is ideal for providing ventilation and cooling in a variety of settings. Specifications

Nominal Size: 18" (effective blade diameter: 450mm)

Voltage: 230V~ 50Hz

Power: 60W

Fan Blades: 5 high-airflow plastic blades

Grille: Plastic safety protective grille

Functions: 3-speed settings, automatic oscillation (left-to-right), adjustable height

Materials & Construction

The unit is constructed from impact-resistant engineering plastic, featuring a telescopic metal stand. It includes a large, reinforced, open-design plastic base for enhanced stability. The tightly-spaced front and rear grilles ensure safety, while the dust-optimized motor housing features a smooth surface, making it easy to wipe clean.

Key Features

5-Blade Spiral Design: Delivers a softer, more natural airflow with a longer reach and ample volume.

3-Speed Settings: 0 (Off), 1 (Low), 2 (Medium), and 3 (High) - easily adjustable to suit any environment.

Wide-Angle Oscillation: Press the knob on the back of the motor housing to enable automatic, wide-range oscillation; pull the knob up to lock the fan in a fixed position.

Adjustable Height: The telescopic stand allows you to change the height of the fan head, ensuring comfort whether you are sitting or standing.

Ultra-Quiet Motor: Optimized internal structure provides powerful airflow with minimal vibration and noise-perfect for use while working or resting.

Stable, Open-Design Base: A large, circular, open-style base that balances lightweight portability with excellent stability, preventing the fan from tipping over.

Tightly-Spaced Safety Grille: Features a fine-mesh design to minimize the risk of accidental contact-ideal for households with children.

Quick-Assembly Design: Includes all necessary components; no special tools required-simply follow the manual to complete assembly in minutes.

Assembly Steps

1. Secure the stand to the base using 4 screws.

2. Slide the base cover over the top of the stand to conceal the connection point.

3. Attach the motor housing to the top of the stand pole and tighten the locking screw.

4. Install the rear grille and secure it with the nut. Align the fan blade with the motor shaft, slide it into place, and fasten it with the blade cap.

5. Align the front grille, snap all the clips into place, and ensure it is securely attached to complete the assembly.

Operating Instructions

1. Plug the power cord into a standard 230V-50Hz electrical outlet.

2. Use the speed selector switch to adjust the airflow: 0 for off, 1 for low speed, 2 for medium speed, and 3 for high speed.

3. To enable oscillation, press down the oscillation knob located on the back of the motor housing; to stop oscillation, pull the knob upward.

Important Reminder: Always unplug the device before assembly or cleaning. Never perform maintenance while the unit is connected to a power source!

Intended Use

Suitable for ventilation and cooling in various settings, such as living rooms, bedrooms, rental properties, convenience stores, small shops, offices, warehouses, and temporary outdoor stalls.

Safety Warnings and Maintenance

Do not touch the fan blades with your hands or any hard objects while they are still in motion, as this may cause injury.

Do not pull the power cord forcefully, as this could damage the cord or the plug.

If the power cord is damaged, please contact a professional technician for repair; do not attempt to disassemble the motor yourself.

Always disconnect the power before cleaning. You may remove the front grille and fan blades and wipe them down with a soft, damp cloth. Do not rinse the entire unit with water, and avoid striking or bending the fan blades.

Do not use the fan in areas exposed to rain or near high-temperature heat sources. If the unit will not be used for an extended period, unplug it and store it in a dry place.

What's in the box
2 X 18-Inch Plastic Floor Fan, 3-Speed Settings, 5-Blade Airflow
