Tp-Link Tl-Sg1016De 16-Port Gigabit Rackmount Smart Switch

TP-Link TL-SG1016DE 16-Port Gigabit Rackmount Smart Switch

• 16 10/100/1000Mbps RJ45 ports
• Provides network monitoring, traffic prioritization and VLAN features
• Innovative energy-efficient technology reduces power output by up to 18%
• Simple network set-up on top of plug-and-play connectivity
• Web-based user interface and management utility simplify configuration



HARDWARE FEATURES
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1q, IEEE 802.1p
Interface	16 10/100/1000Mbps RJ45 Ports
AUTO Negotiation/AUTO MDI/MDIX
Network Media	10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
Fan Quantity	Fanless
Physical Security Lock	No
Power Supply	100-240VAC, 50/60Hz
Power Consumption	Maximum: 11.73W (220V/50Hz)
Dimensions ( W x D x H )	11.6*7.1*1.7 in. (294*180*44 mm)
Mounting	Rack Mountable
Max Power Consumption	19.15W (220V/50Hz)
Max Heat Dissipation	65.34 BTU/h
PERFORMANCE
Switching Capacity	32Gbps
Packet Forwarding Rate	23.8Mpps
MAC Address Table	8K
Packet Buffer Memory	512KB
Jumbo Frame	9KB
SOFTWARE FEATURES
Quality of Service	Support Port-based/802.1p/DSCP priority
Support 4 priority queues
Rate Limit
Storm Control
L2 Features	IGMP Snooping V1/V2/V3
Static Link Aggregation
Port Mirroring
Cable Diagnostics
Loop Prevention
VLAN	Supports up to 32 VLANs simultaneously (out of 4K VLAN IDs)
MTU/Port/Tag VLAN
Transmission Method	Store-And-Forward
OTHERS
Certification	FCC, CE, RoHS
Package Contents	TL-SG1016DE
Power Cord
Installation Guide
Resource CD
Rackmount Kit
Rubber Feet
System Requirements	Microsoft® Windows® for running Utility
