USB to RS485 Communication Module Bidirectional Serial Line Converter

USB to RS485 Communication Module Bidirectional Serial Line Converter

USB 2.0 to RS485 Converter and all kinds of 485 interface docking, transmission distance up to 1000 meters;Mainchip:CP2102(SILICON LABS) ,Industrial chip, high quality, super stable. The Lead PINS include: A +, B-, GND ,GND,5V0;Industrial Product, With 15KV ESD protection and TVS overvoltage protection
Features:1. Industrial level protection: TVs transient suppression protection, ESD protection, surge protection, AB signal line short circuit and power supply short circuit protection (short circuit does not burn
2. Transmission distance up to 1200 meters (tested at 9600bps);3. Support the baud rate of 921600, which is much higher than 115200, and the baud rate of pairwise mutual transmission is higher
4. Multi system supports hot plug, WIN98 / CE / 2000/2003/2008 / xpwn7n8 / wn10 Vista / Linux / Mac OS X system, and USB interface can be hot plug
5. Automatic identification and control of data transmission direction, without any handshake signal (such as RTS, DTR, etc.) and without jumper setting, mode conversion can be realized to ensure compliance with existing communication software and interface hardware;6. With TXD, RXD indicator light
Specification Description:
1. Power supply: usb5v
2. Transmission distance: up to 1200m (9600bps)
3. Chip scheme: ch340
4. Communication protocol: hardware only, not limited by protocol
5. Baud rate: up to 921600bps, supporting mutual transmission supports higher baud rate
6. Protection: TVs transient suppression protection, ESD protection, surge protection, AB signal line short circuit and power supply short circuit protection (short circuit does not burn)
7. Temperature range:-40 Celsius-80 Celsius
8. Provide external 5V power supply with fuse to limit current
9. Support system: support hot plug, support WIN98 / CE / 2000/2003/2008 / xpwn7wn8 / wn10 / Vista / Linux / Mac OS X system, USB interface can be hot plug
10. Automatic identification and control of data transmission direction can realize mode conversion without any handshake signal (such as RTS, DTR, etc.) and jumper setting, so as to ensure compliance with existing communication software and interface hardware.
11 weight: 16g
colour: blue
Material: ABS
size: 70x27x13mm

Package Contents:
1xusb to rs485 communication module
Only the above package content, other products are not included.
Note: Light reflection and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.

What's in the box
1xusb to Rs485 Communication Module
